Discontinued
185g, 7.9mm thickness
6.0" - 1080 x 1920 pixels
Android 6.0 (Marshmallow), upgradable to 7.0 (Nougat), EMUI 4
Kirin 950 (16 nm)
32GB 3GB RAM, 64GB 4GB RAM, 128GB 4GB RAM
Li-Po 4000 mAh, non-removable
18W wired, 37% in 30 min
Brand:
(5 votes)
Launch
Announced :
2015, November. Released 2015, November
Network
Technology :
GSM / HSPA / LTE
Speed :
HSPA 42.2/5.76 Mbps, LTE (2CA) Cat6 300/50 Mbps
2G bands :
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (optional)
1, 2, 3, 4, 5, 6, 7, 8, 12, 17, 18, 19, 20, 26, 28, 38, 39, 40 - NXT-L09
3G bands :
HSDPA 800 / 850 / 900 / 1700(AWS) / 1900 / 2100 - NXT-L29, NXT-L09
4G bands :
1, 2, 3, 4, 5, 6, 7, 8, 12, 17, 18, 19, 20, 26, 38, 39, 40 - NXT-L29
Body
Dimensions :
157.1 x 80.6 x 7.9 mm (6.19 x 3.17 x 0.31 in)
SIM :
Nano-SIM (NXT-L09)Nano-SIM + Nano-SIM (NXT-L29)
Build :
Glass front (Gorilla Glass 3), aluminum back, aluminum frame
Display
Size :
6.0 inches, 98.7 cm2 (~78.0% screen-to-body ratio)
Resolution :
1080 x 1920 pixels, 16:9 ratio (~368 ppi density)
Protection :
Corning Gorilla Glass 3
Platform
OS :
Android 6.0 (Marshmallow), upgradable to 7.0 (Nougat), EMUI 4
Chipset :
Kirin 950 (16 nm)
CPU :
Octa-core (4x2.3 GHz Cortex-A72 & 4x1.8 GHz Cortex A53)
Memory
Card Slot :
microSDXC (uses shared SIM slot)
Internal :
32GB 3GB RAM, 64GB 4GB RAM, 128GB 4GB RAM
Sound
Comms
WLAN :
Wi-Fi 802.11 a/b/g/n/ac, dual-band, DLNA, Wi-Fi Direct
Bluetooth :
4.2, A2DP, EDR, LE
Positioning :
GPS, GLONASS, BDS
Features
Sensors :
Fingerprint (rear-mounted), accelerometer, gyro, proximity, barometer, compass
Battery
Stand-by :
Up to 528 h (3G)
Type :
Li-Po 4000 mAh, non-removable
Charging :
18W wired, 37% in 30 min
Misc
Colors :
Champagne Gold, Moonlight Silver, Space Gray, Mocha Brown
SAR EU :
1.46 W/kg (head) 0.21 W/kg (body)
Models :
NXT-AL10, NXT-CL00, NXT-DL00, NXT-TL00, NXT-L09, NXT-L29
SAR :
1.49 W/kg (head) 0.32 W/kg (body)
Main Camera
Features :
Dual-LED dual-tone flash, panorama, HDR
Video :
1080p@60fps, 1080p@30fps, 720p@120fps
Single :
16 MP, f/2.0, 27mm (wide), 1/2.8", PDAF, OIS
Selfie camera
Single :
8 MP, f/2.4, 26mm (wide)
Tests
Performance :
Basemark OS II 2.0: 2017Basemark X: 15593
Display :
Contrast ratio: 1361:1 (nominal), 2.949 (sunlight)
Loudspeaker :
Voice 67dB / Noise 65dB / Ring 66dB
Battery (old) :
Endurance rating 103h
Audio quality :
Noise -97.8dB / Crosstalk -97.3dB
