Discontinued
144g, 6.4mm thickness
5.2" - 1080 x 1920 pixels
Android 4.4.2 (KitKat), upgradable to 6.0 (Marshmallow), EMUI 3.1
Kirin 930 (28 nm)/ Kirin 935 (28 nm)
16GB 3GB RAM, 32GB 3GB RAM, 64GB 3GB RAM
Li-Po 2680 mAh, non-removable
Brand:
(5 votes)
Launch
Announced :
2015, April. Released 2015, April
Network
Technology :
GSM / HSPA / LTE
Speed :
HSPA 42.2/5.76 Mbps, LTE (2CA) Cat6 300/50 Mbps
2G bands :
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2
HSDPA 800 / 850 / 900 / 1700 / 1800 / 1900 / 2100 - L09
3G bands :
HSDPA 850 / 900 / 1700 / 1900 / 2100 - UL00
4G bands :
1, 3, 4, 7, 38, 39, 40, 41 - UL00
Body
Dimensions :
144.9 x 72.1 x 6.4 mm (5.70 x 2.84 x 0.25 in)
SIM :
Nano-SIM + Nano-SIM
Build :
Glass front (Gorilla Glass 3), glass back (Gorilla Glass 3), aluminum frame
Display
Size :
5.2 inches, 74.5 cm2 (~71.4% screen-to-body ratio)
Resolution :
1080 x 1920 pixels, 16:9 ratio (~424 ppi density)
Protection :
Corning Gorilla Glass 3
Platform
OS :
Android 4.4.2 (KitKat), upgradable to 6.0 (Marshmallow), EMUI 3.1
Chipset :
Kirin 930 (28 nm)/ Kirin 935 (28 nm)
CPU :
Octa-core (4x2.0 GHz Cortex-A53 & 4x1.5 GHz Cortex-A53)
Memory
Card Slot :
microSDXC (uses shared SIM slot)
Internal :
16GB 3GB RAM, 32GB 3GB RAM, 64GB 3GB RAM
Sound
Comms
WLAN :
Wi-Fi 802.11 a/b/g/n, Wi-Fi Direct, DLNA
Bluetooth :
4.1, A2DP, LE
Positioning :
GPS, GLONASS/ BDS (market dependant)
Features
Sensors :
Accelerometer, gyro, proximity, compass
Battery
Type :
Li-Po 2680 mAh, non-removable
Misc
Colors :
Titanium Grey, Mystic Champagne (16 GB model)Carbon Black, Prestige Gold (64 GB model)
SAR EU :
0.47 W/kg (head) 1.72 W/kg (body)
Models :
GRA-UL00, GRA-L09, GRA-UL10, GRA-TL00, GRA-CL10
SAR :
1.41 W/kg (head) 1.23 W/kg (body)
Main Camera
Features :
Dual-LED dual-tone flash, panorama, HDR
Single :
13 MP, f/2.0, 28mm (wide), 1/3.1", 1.12µm, AF, OIS
Selfie camera
Single :
8 MP, f/2.4, 26mm (wide)
Tests
Performance :
Basemark OS II 2.0: 1112Basemark X: 6307
Display :
Contrast ratio: 1516 (nominal), 2.196 (sunlight)
Loudspeaker :
Voice 66dB / Noise 66dB / Ring 68dB
Battery (old) :
Endurance rating 64h
Audio quality :
Noise-91.5dB / Crosstalk -93.5dB
