Discontinued
155g, 8mm thickness
5.8" - 1440 x 2960 pixels
Android 7.0 (Nougat), upgradable to Android 9.0 (Pie), One UI
Exynos 8895 (10 nm) - EMEAQualcomm MSM8998 Snapdragon 835 (10 nm) - USA & China
64GB 4GB RAM
Li-Ion 3000 mAh, non-removable (11.55 Wh)
15W wired, QC2 Wireless (Qi) (market dependent)
Brand:
(5 votes)
Launch
Announced :
2017, March 29. Released 2017, April 24
Network
Technology :
GSM / HSPA / LTE
Speed :
HSPA 42.2/5.76 Mbps, LTE (5CA) Cat16 1024/150 Mbps
2G bands :
GSM 850 / 900 / 1800 / 1900 - SIM 1 & SIM 2 (dual-SIM model only)
3G bands :
HSDPA 850 / 900 / 1700(AWS) / 1900 / 2100
4G bands :
1, 2, 3, 4, 5, 7, 8, 12, 13, 17, 18, 19, 20, 25, 26, 28, 32, 66, 38, 39, 40, 41
Body
Dimensions :
148.9 x 68.1 x 8 mm (5.86 x 2.68 x 0.31 in)
SIM :
Nano-SIMNano-SIM + Nano-SIM
Build :
Glass front (Gorilla Glass 5), glass back (Gorilla Glass 5), aluminum frame
IP68 dust tight and water resistant (immersible up to 1.5m for 30 min)
Display
Type :
Super AMOLED, HDR10
Size :
5.8 inches, 84.8 cm2 (~83.6% screen-to-body ratio)
Resolution :
1440 x 2960 pixels, 18.5:9 ratio (~570 ppi density)
Protection :
Corning Gorilla Glass 5
3D Touch (home button only)
Always-on display
Platform
OS :
Android 7.0 (Nougat), upgradable to Android 9.0 (Pie), One UI
Chipset :
Exynos 8895 (10 nm) - EMEAQualcomm MSM8998 Snapdragon 835 (10 nm) - USA & China
CPU :
Octa-core (4x2.3 GHz Mongoose M2 & 4x1.7 GHz Cortex-A53) - EMEAOcta-core (4x2.35 GHz Kryo & 4x1.9 GHz Kryo) - USA & China
GPU :
Mali-G71 MP20 - EMEAAdreno 540 - USA & China
Memory
Card Slot :
microSDXC (uses shared SIM slot) - dual SIM model only
Sound
Comms
WLAN :
Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct
Bluetooth :
5.0, A2DP, LE, aptX
Positioning :
GPS, GLONASS, BDS, GALILEO
Features
Sensors :
Iris scanner, fingerprint (rear-mounted), accelerometer, gyro, proximity, compass, barometer, heart rate, SpO2
Samsung DeX (desktop experience support)
ANT+
Bixby natural language commands and dictation
Samsung Pay (Visa, MasterCard certified)
Battery
Talk time :
Up to 20 h (3G)
Type :
Li-Ion 3000 mAh, non-removable (11.55 Wh)
Charging :
15W wired, QC2
Wireless (Qi) (market dependent)
Misc
Colors :
Midnight Black, Orchid Gray, Arctic Silver, Coral Blue, Maple Gold, Rose Pink, Burgundy Red
SAR EU :
0.32 W/kg (head) 1.27 W/kg (body)
Models :
SM-G950FD, SM-G950W, SM-G950S, SM-G950K, SM-G950L, SM-G9500, SM-G950A, SM-G950P, SM-G950T, SM-G950U, SM-G950V, SM-G950F, SM-G950U1, SM-G950N, SC-02J, SCV36, SM-G950, G950F
SAR :
0.44 W/kg (head) 0.75 W/kg (body)
Main Camera
Features :
LED flash, auto-HDR, panorama
Video :
4K@30fps, 1080p@30/60fps, 720p@240fps, HDR, stereo sound rec., gyro-EIS, OIS
Single :
12 MP, f/1.7, 26mm (wide), 1/2.55", 1.4µm, dual pixel PDAF, OIS
Selfie camera
Dual :
8 MP, f/1.7, 25mm (wide), 1/3.6", 1.22µm, AF
2 MP (dedicated iris scanner camera)
Tests
Performance :
AnTuTu: 199022 (v7)
GeekBench: 6656 (v4.4)
GFXBench: 13fps (ES 3.1 onscreen)
Display :
Contrast ratio: Infinite (nominal), 4.768 (sunlight)
Loudspeaker :
Voice 66dB / Noise 70dB / Ring 72dB
Battery (old) :
Endurance rating 84h
Audio quality :
Noise -92.5dB / Crosstalk -92.8dB
